MCHALE BALERS AND BALE WRAPPERS NEW ZEALAND

McHale 991BE - Fully Automated Electric Trailed Round Bale Wrapper

Packed with practical and reliable features, the 991 round bale wrapper range is designed with the efficient operator in mind.

The McHale 991 range of round bale wrappers sets the pace for efficient and effective round bale wrapping. The 991 round bale wrapping range features practical design, quality components and precision engineering, making the McHale bale wrapping range the first choice for contractors and farmers.

Packed with practical and reliable features, the 991 round bale wrapper range is designed with the efficient operator in mind. Round bale wrapper users should look towards the hydraulically operated cut and tie system, the efficient round bale wrapper dispenser which maximises film usage, and the 991 round bale wrappers patented ground supported damper system.

Like all McHale round bale wrappers, the high output fully automatic 991BE bale wrapper will deliver a tightly wrapped silage bale which contains all the natural juices, ensuring increased nutritional value, while improving environmental protection.

High quality and consistent performance in all types of conditions and terrain.

  • Hydraulically operated cut and tie system
  • Efficient despenser
  • Patented ground supported damper system
  • High output for tightly wrapped bales

Specifications

Trailed Model [Round] 991BE

Transport Length 5.7m (19’)
Working speed-table (up to) 30 rotations/min
Electrical Requirements 991BE 12v/ from battery
Lift Capacity @ 170 bar 1100 kg. (2425 lbs.)
Hydraulic connections 2 x 1/2” male quick releases
Wheel Dimensions 350 x 50 x 16
Hydraulic Requirements 22 l/min @ 170 bar
Weight (unladen) 1870 kg. (4123 lbs.)
Film Layers 2 + 2 or 2 + 2 + 2
Total Height 2.46m (8’1”)
Dispenser - Aluminium (70-55%) 750/500mm
Height to top of rollers 1.25m (4’2”)
Protection Mechanism Shear bolt/ roll pin
Transport Width 2.45m (8’2”)
Attachment to tractor Tow bar
Driver Control 991BE Elec. box
Export Packaging Dimensions per stack of 2
Width/Height 2.3m (7’7”)
Length 3.27m (10’9”)
